Top-Of-The-Line Foundation Drilling Equipment in Australia

Drilling Equipment & Skilled Operator

We love our drilling equipment at Fenwick Drilling and take immense pride in its construction and use. Our experienced team is trained to handle the machines with care and can quickly address any issues should they arise. The variety and customisability of the machines we have enable us to work on almost any site, even the more troublesome ones.

A concrete mixer is pouring concrete under a bridge.
A yellow pipe is going through a tunnel.
A man is standing next to a large metal pipe in front of a large excavator.

Drilling Equipment for Diverse Site Needs

We use specialised rock augers, core barrels, mud buckets and clean-out buckets, all made at our professional workshop. Some of our specialised drilling equipment lets us drill at low head height (from 3.4 metres), as well as drill for wick holes. Additionally, we can supply bobcats, excavators and 10t tippers. All of our machines are mine-compliant.

Low Head Height Machines

A man is sitting in the driver 's seat of a large excavator.
A large machine is sitting on top of a pile of dirt on a construction site.
A construction site with a crane and pipes in the dirt.
An aerial view of a construction site with a crane on the ground.
  • MAIT HR130
  • MAIT EC35
  • MAIT BABY DRILL

Machines for Hire

MAIT HR260 THD - TRACK MACHINE

86t/30-tonne torque

Drill up to 3m diameter

30m Kelly bar

Can drill a wider diameter with the right ground conditions

MAIT HR130 - TRACK MACHINE

Torque upgraded to 18t

Piling mode drills 30m

Drills up to 1.5m diameter

Low head height drills up to 20m

Mast height - 7.3m

Comes fully assembled to the site

MAIT EC35 - TRACK MACHINE

6 tonne torque

5.2m mast height

Interlocking Kelly bar

To 16m in depth

Drills up to 900mm in diameter

1x MAIT BABY DRILL

Low head height rig - remote control track machine for confined & tricky spaces

4.5-tonne torque

1x 8m locking height with this bar is 3.4m

1x 15m bar – 4.2m height up to 880mm diameter

1X WATSON 2500TM DRILLING RIG

On an 8-wheel drive truck

12-tonne torque

Drill diameter - 350mm to 1.500mm

Drill depth -18m

1X WATSON 2500TM DRILLING RIG

On a twin-steer truck

12-tonne torque

Drill diameter - 350mm to 1.800mm

Drill depth – 18m

FENWICK DRILLING RIG

Drill diameter: 300mm to 900mm

Drill depth: 9m

FENWICK DRILLING RIG

Drill diameter: 300mm to 900mm

Drill depth: 8m

1 x 480 PENGO DRILLING RIG

Drill diameter: 350mm to1.200mm

Drill depth: 11m

33T EXCAVATOR WITH DRILLING HEADS

Drill diameter: 300mm to 1.200mm

Drill depth: 8m

Rock breaker and all attachments

Extension works as required

10T EXCAVATOR WITH ALL ATTACHMENTS

SPECIALISED EQUIPMENT

Vibrating hammer

Tremmie tubes

Steel liners

Call us on 07 3800 8311 today to arrange an onsite visit and free quote.
